Product Information
Designed for playgrounds, shopping areas, and other high-traffic locations, the 4300 Series provides a cost-effective and durable drinking solution. This fountain features a chrome-plated brass bubbler locked to a stainless steel receptor, ensuring long-term performance and reliability.
The unit includes a self-closing, chrome-plated valve and a 12” diameter floor flange, creating an exceptionally sturdy mounting base. Automatic flow regulation ensures consistent water pressure for an optimal drinking experience.
Features
✔ Cost-Effective Drinking Fountain – Designed for high-traffic environments where budget is a factor.
✔ Sturdy Mounting Base – 12” diameter floor flange provides exceptional stability.
✔ Chrome-Plated Brass Bubbler – Locked to stainless steel receptor for added security.
✔ Cross-Arm Self-Closing Valve – Provides controlled water flow (lever handle or push-button options available).
✔ Adjustable Flow Regulation – Ensures consistent water pressure.
✔ Vandal-Resistant Access Plates – Allows easy maintenance while preventing tampering.
✔ Stainless Steel Supply Fittings – Reinforced tubing for durability.
✔ In-Line Mesh Screen Strainer – Prevents debris from entering the water system.
✔ Powder-Coated Finish – Standard woodland green for added weather resistance.
✔ Secure Water Supply Control – 1/2” IPS lock shield screwdriver stop prevents unauthorized tampering.
✔ Efficient Drainage System – 1-1/4” IPS waste pipes included for proper water disposal.
Available Models
• 4300 – Lever handle model
• 4400 – Push-button, surface-mounted model
• 4430 – Lever handle, surface-mounted model
Optional Features
SMP-6 | Surface Mounting Plate
85 | Valve Box with Lid
96 | Sand Strainer Plate
SS | Stainless Steel Finish
Specifications
| Feature | Details |
|---|---|
| Available Models | Economy Single Pedestal Drinking Fountains |
| Material | Heavy-duty steel pipe with welded steel plates (4400 & 4430 models) |
| Finish Options | Woodland green powder coat (stainless steel finish available) |
| Mounting Type | Surface-mounted plate (SMP-6 included for select models) |
| Surface Requirements | Must be installed on a dry, level surface |
| Waste Drainage | 1.25-inch (32 mm) IPS waste pipes included |
| Water Supply | 0.5-inch (12.7 mm) IPS lock shield screwdriver stop |
Available Models & Dimensions
| Model | Type | Height | Base Diameter | Mounting |
|---|---|---|---|---|
| 4300 | Standard Pedestal Fountain | 35 inches (89 cm) | 12 inches (30 cm) | N/A |
| 4400 | Single with Surface Mount | 36 inches (91 cm) | 12 inches (30 cm) | Surface-mounted plate |
| 4430 | Single with Surface Mount & Lever Handle | 36 inches (91 cm) | 12 inches (30 cm) | Surface-mounted plate |
⚠ Note: All dimensions are subject to a manufacturing variance of ± 1/4″ (6 mm).
