Name: Willoughby CWBFD-3WM Wall-Mounted Outdoor Bottle Filler with Drinking Fountains For Parks
Brand: Willoughby
SKU: CWBFD-3WM
Price: 3999.98 USD
Availability: InStock

Willoughby CWBFD-3WM Wall-Mounted Outdoor Bottle Filler with Drinking Fountains For Parks

by Willoughby

SKU CWBFD-3WM

Save $1,000.00

$4,999.98

$4,999.98 - $4,999.98

$4,999.98

$3,999.98

$3,999.98 - $3,999.98

$3,999.98

Authorized Dealer

☎ Questions? Call Us (314) 200-1341

Why Shop With Us?

Free
Shipping

No Sales
Tax

Manufacturer
Warranty

30 Day
Returns

Product Description

The Willoughby CWBFD-3WM Series Wall-Mounted Bottle Filler with Drinking Fountains offers a sleek and durable hydration solution for outdoor recreational spaces, parks, and public areas. Designed to minimize plastic waste and encourage sustainable practices, this multi-user fixture is both practical and eco-conscious.

Fabricated from 14-gauge, Type 304 stainless steel, this unit includes recessed-mounted solid stainless steel pushbuttons or an optional battery-operated infrared sensor for the bottle filler. The lead-free, self-closing valves are designed for minimal user effort, requiring less than 5 lbs. of force with flow controls set at 1.0 GPM for the bottle filler and 0.5 GPM for the drinking fountains, ensuring efficient water delivery.

Model CWBFD-3WM is ANSI/NSF 61, Section 9 compliant and comes powder coated in your choice of color to suit any outdoor setting.

Features

✓ Wall-mounted stainless steel construction
✓ Dual-access: Bottle filler & drinking fountains
✓ Recessed pushbutton or optional infrared sensor activation
✓ 1.0 GPM bottle filler & 0.5 GPM bubbler flow control
✓ Lead-free, self-closing valves
✓ Powder coat color options available
✓ Made in the USA

Specifications

Model: CWBFD-3WM
Material: 14-Gauge Type 304 Stainless Steel
Mounting Type: Wall-Mounted
Flow Rate: 1.0 GPM (bottle filler), 0.5 GPM (fountains)
Valve: Lead-Free, Self-Closing
Activation: Mechanical Pushbutton / Optional Sensor
Finish: Satin Stainless + Powder Coat
Compliance: ANSI/NSF 61, Section 9

Lead Time

Made to Order — Ships in 8–10 weeks
This item is built just for you. Each piece is made to order, ensuring exceptional craftsmanship and attention to detail. A short wait for a product designed to last decades is a worthwhile investment.

Need it sooner? We also offer faster shipping options. Contact us to explore available alternatives.

Willoughby Policies

Shipping/Return Policy: Fully custom-made to order fixtures so no returns
Warranty: Each fixture has a 1-year warranty

Downloads

Spec Sheet

Let customers speak for us

from 5 reviews

Redstone Hills Community Park District

They are very communicative and make sure you're always up to date on everything. The fast shipping program is awesome, all 3 fountains arrived in less than a week from the time I placed the order and in perfect condition, thanks guys

Alex

07/10/2025

Stern-Williams 7700 Public Drinking Water Fountain & Bottle Filler For Parks – Pet Fountain Option

Facundo was great to deal with and made sure I was taken care of completely

Facundo was great to deal with and made sure I was taken care of completely.

RLTurner

07/08/2025

Stern-Williams 6800 Beach Shower Towers – ADA Compliant, Available with Grab Bars

Work pretty well

That makes the installation so much easier for us, and the delivery was very fast, thanks.

Adam O.

06/18/2025

SMP-6 surface mounting

Awesome product and company to buy from

Great experience from start to finish. The product is high quality, arrived on time, and communication was excellent.

Alex Tomkinson

06/18/2025

Avalon A50-C In-Wall Bottle Filler with Chiller – WiFi Enabled, Cold Water, and UV Sterilization (Refrigerated)

Fast delivery

Super fast shipping and great communication. The product arrived even earlier than expected. You can tell they really care about doing things right and staying in touch with their customers, highly recommend!

Kenly L.

06/13/2025

Avalon Dual Replacement Water Filters – For Bottleless Coolers with Two-Stage Filtration

Can this be installed in freezing climates?

Willoughby fountains are not designed for freezing climates, which is why we strongly recommend winterizing the unit before temperatures drop. Winterization is a quick process that involves draining the water lines and shutting off the supply to prevent damage from freezing, it helps protect your investment during cold months.

Are Willoughby fountains customizable?

Yes. You can add pet bowls, hose bibbs, bottle fillers, and more. Pick your color, finish, and features. Check the “Add-On Options” sheet in the product images, or just ask us for help.

Are these fountains good for parks, schools, or public spaces?

Absolutely. They’re made for heavy use, vandal resistance, and year-round outdoor performance. Perfect for parks, campuses, sports fields, and more.

Is it made in the USA?

Yes, 100% handmade in the USA with high-quality materials.

How do drinking fountains work?

Drinking fountains connect to a water supply line that runs underground. When you press the button, water flows up through internal piping and out through the bubbler, all powered by water pressure. No electricity or pump is needed. The pipes and valves are protected inside the unit and below the surface, making the system reliable and built to last.

Is it safe to drink from these fountains?

Yes. They’re connected to your local treated water supply, the same safe water you drink at home. Many models also include strainers or optional filters for extra peace of mind.

Do you have a fast shipping option?

Willoughby fountains are made to order using high-quality stainless steel, so they don’t qualify for fast shipping. Each unit is built from scratch, and the wait is worth it.

If you need a fountain sooner, check out our Fast Shipping Program here: Fast Shipping Program

How can I install this?

Most models need a below-ground water connection and a concrete pad. We recommend using a licensed contractor. Every fountain comes with clear manuals and specs to make the job smooth.

Do these fountains come with a filter or cooling system?

Not by default. These outdoor models don’t use electricity, so they don’t chill or filter water, but some include inline strainers. Ask us about upgrade options if you need filtration.

Are these shower towers good for beaches or public areas?

Yes. They’re made from rust-resistant stainless steel and built to handle sand, salt, sun, and heavy daily use. Perfect for beaches, pools, campsites, and other high-traffic outdoor spaces.

Are these shower towers good for beaches or public areas?

Yes. They’re made from rust-resistant stainless steel and built to handle sand, salt, sun, and constant use. Ideal for beaches, pools, campsites, and outdoor facilities.

What are those fountains or shower towers made of?

100% stainless steel, made to last decades in harsh environments
