Product Information
The WDF-1040 Series offers barrier-free wall-mounted drinking fountains available in contemporary or classic styling to fit various environments. Designed for durability, these fountains are available in four color options and frost proof (-FP) models for cold-weather installations.
Built with a stainless steel receptor, a vandal-resistant drain plug, and reinforced stainless steel supply fittings, this series ensures reliable performance in public and commercial spaces.
Features
✔ Barrier-Free Design – ADA-compliant for accessible drinking solutions.
✔ Durable Construction – Available in white polymarble and terrazzo finishes.
✔ Push Button Valve – Located on the front for ease of use.
✔ Vandal-Resistant Components – Includes stainless steel access plates for added protection.
✔ Stainless Steel Supply Fittings – Reinforced tubing for long-term durability.
✔ Available in Frost Proof (-FP) Models – Prevents freezing in cold environments.
✔ Secure Water Supply Control – 1/2” IPS lock shield screwdriver stop prevents tampering.
✔ Efficient Drainage System – 1-1/4” IPS waste pipes included for proper water disposal.
✔ Standard Mounting Plate – Stainless steel bottom plate included for secure installation.
Available Models
White Polymarble Fountains
WDF-1040, WDF-1040-FP, WDF-10201
Polished Terrazzo Fountains
WDF-1000, WDF-1000-FP, WDF-1050, WDF-1050-FP
Light Etched Terrazzo Fountains
WDF-1001, WDF-1001-FP, WDF-1051, WDF-1051-FP, WDF-1060-C, WDF-1060-C-FP
Medium Etched Terrazzo Fountains
WDF-1061-C, WDF-1061-C-FP
Specifications
| Feature | Details |
|---|---|
| Available Models | Single Wall Mounted Drinking Fountains – Barrier-Free & Frost Proof Options |
| Material | White polymarble or terrazzo construction |
| Finish Options | Polished, light etched, or medium etched terrazzo finishes |
| Mounting Type | Wall-mounted with standard mounting plate |
| Surface Requirements | Must be installed on a dry, level wall surface |
| Waste Drainage | 1.25-inch (32 mm) IPS waste pipes included |
| Water Supply | 0.5-inch (12.7 mm) IPS lock shield screwdriver stop |
Dimensions
| Model | Type | Height | Width | Length |
|---|---|---|---|---|
| WDF-1000 | Polished Terrazzo | 10 inches (25 cm) | 12 inches (30 cm) | 12.88 inches (33 cm) |
| WDF-1001 | Light Etched Terrazzo | 10 inches (25 cm) | 12 inches (30 cm) | 12.88 inches (33 cm) |
| WDF-1040 | White Polymarble | 15 inches (38 cm) | 14.25 inches (36 cm) | 12.25 inches (31 cm) |
| WDF-1041 | White Polymarble | 15 inches (38 cm) | 14.25 inches (36 cm) | 12.25 inches (31 cm) |
| WDF-1050 | Barrier-Free Fountain (Polished) | 10.88 inches (28 cm) | 12 inches (30 cm) | 22 inches (56 cm) |
| WDF-1051 | Barrier-Free Fountain (Light Etched) | 10.88 inches (28 cm) | 12 inches (30 cm) | 22 inches (56 cm) |
| WDF-1060-C | Barrier-Free Fountain (Light Etched) | 9.5 inches (24 cm) | 14 inches (36 cm) | 19.75 inches (50 cm) |
| WDF-1061-C | Barrier-Free Fountain (Medium Etched) | 9.5 inches (24 cm) | 14 inches (36 cm) | 19.75 inches (50 cm) |
⚠ Note: All dimensions are subject to a manufacturing variance of ± 1/4″ (6 mm).
