Product Description
Want to install a hydration station so sleek and powerful your building looks smarter just for having it? The Elkay LZWS-SS28K is a fully recessed, ADA-compliant, three-station hydration solution with hands-free sensor activation, NSF-certified filtration, and chilled water delivery—all wrapped in a premium stainless steel design.
This setup includes a vandal-resistant bottle filler with antimicrobial protection, a real drain to eliminate standing water, and Elkay’s Green Ticker™ to remind users they’re reducing waste with every refill. Designed to install flush into the wall, it’s the ultimate combo of function, durability, and aesthetics.
If you’re upgrading a hospital, airport, university, or government building, this is the unit that says: “We don’t cut corners.”
Features
✓ Fully Recessed, In-Wall Design – Sleek, modern, and ideal for high-traffic indoor spaces
✓ Touchless Bottle Filler – Sensor-activated with automatic shut-off to reduce contamination
✓ ADA-Compliant Bi-Level Fountains – Push-button operation for easy access by all users
✓ NSF-Certified Filtration – 3,000-gallon filter reduces lead, chlorine, odor, and particulates
✓ Built-In Green Ticker™ – Shows plastic bottles saved in real time
✓ Antimicrobial Protection – Key components infused with silver ion agent to inhibit mold and mildew
✓ Real Drain System – Eliminates standing water, reducing maintenance and bacteria buildup
✓ Chilled Hydration – Delivers up to 8.0 GPH of refrigerated water
✓ Laminar Flow – Clean, splash-free filling at 1.1 GPM
✓ Certified Safe – Compliant with ADA, NSF 42, 53, 61, 372, 401, and UL 399 standards
Specifications
| Feature | Details |
|---|---|
| Brand | Elkay |
| Model Number | LZWS-SS28K |
| Type | Recessed Bottle Filler with Bi-Level Refrigerated Fountain |
| Number of Stations | 3 (Bottle Filler + Dual Fountains) |
| Material | Stainless Steel |
| Activation | Sensor (Bottle Filler), Push Button (Bubblers) |
| Chilling Capacity | 8.0 GPH (Gallons Per Hour) |
| Filtered | Yes – NSF 42 & 53 Certified |
| Power Supply | 115V / 60Hz |
| Mounting Option | Wall Mount (In-Wall Frame) |
| Installation Location | Indoor Only |
| Dimensions | Length: 58-1/4 inches, Width: 18 inches, Height: 40-13/16 inches |
| Shipping Dimensions | Length: 42 inches, Width: 83-15/16 inches, Height: 46 inches |
| Shipping Weight | 167 lbs |
| Included With Product | Bottle Filler (LZWSM8C), Fountain (LNTED8C), 2 Chillers (ECH8), Filter (EWF3000), Frames (MF200 & MFWS100) |
| Certifications | ADA, ICC A117.1, NSF 42, 53, 61, 372, 401, UL 399, ASME A112.19.3, CSA B45.4, CAN/CSA C22.2 No. 120, GreenSpec |
| Country of Origin | USA |
| Ideal For | Airports, Universities, Hospitals, Government Buildings |
Warranty
Elkay offers a 5-Year Limited Warranty on the refrigeration system and a 1-Year Limited Warranty on other components. For full coverage terms, see Elkay’s official documentation.
